F33P, the triangular truss with equilateral profile geometry for larger loads.
The F33P straight elements lend themselves perfectly for making bending stress resistant spans up to 12 meters (39 feet). Designed for high frequency usage or installations, which demands higher loading.
F33P is using the 3mm wall thickness in the main tube whichassures durability and extra strength.
Made with the fast connection system and approved according the DIN EN 1999-1-1 & 1999-1-1/A2 .
Facts |
|
Specifications F33P | ||
Metric | Imperial | |
Height Width MainTube Braces Weight PinPosition Material Connection | 290 mm 290 mm 50 x 3 mm 20 x 2 mm ~7.5kg/m Diagonal EN AW-6082 T6 Cs5 | 11.42 in 11.42 in 1.97x 0.12 in 0.79 x 0.08 in ~16.5 lbs/m |
- Service Process -
- Service Process -
Professional team and service to create a perfect stage for you
1. Learn Project Place Planning
professional team will have a comprehensive understanding based on the site size and project requirements you provide.
2. Design and determine Program
Professional design team, free design for you to meet your needs.
3. Quotation and contract signing
Once the plan is confirmed, after detailed accounting, we will provide you with a satisfactory quotation!
4. To pay a deposit Arrange production
Reasonable production schedule, Consummate localization, Correction and the Welding technology, brings the best Barrier (Net) quality for you!
5. Product inspection
Casting with details outstanding, in addition to the internal product quality inspection and control standards, but also the European Union ENISO3834 aluminum alloy welding standards and hardware machine processing industry standards, to ensure high quality.
6. Global Trasportation
Professional logistics team, whether you choose logistics or need to deliver to our door, guarantee delivery on time!
![]() | 7. After Sales Services Provide detailed product installation instructions and video demonstrations, one-on-one professional customer service orders, ready to solve any problems for you, so that you can worry more, save time! |
F33P, the triangular truss with equilateral profile geometry for larger loads.
The F33P straight elements lend themselves perfectly for making bending stress resistant spans up to 12 meters (39 feet). Designed for high frequency usage or installations, which demands higher loading.
F33P is using the 3mm wall thickness in the main tube whichassures durability and extra strength.
Made with the fast connection system and approved according the DIN EN 1999-1-1 & 1999-1-1/A2 .
Facts |
|
Specifications F33P | ||
Metric | Imperial | |
Height Width MainTube Braces Weight PinPosition Material Connection | 290 mm 290 mm 50 x 3 mm 20 x 2 mm ~7.5kg/m Diagonal EN AW-6082 T6 Cs5 | 11.42 in 11.42 in 1.97x 0.12 in 0.79 x 0.08 in ~16.5 lbs/m |
- Service Process -
- Service Process -
Professional team and service to create a perfect stage for you
1. Learn Project Place Planning
professional team will have a comprehensive understanding based on the site size and project requirements you provide.
2. Design and determine Program
Professional design team, free design for you to meet your needs.
3. Quotation and contract signing
Once the plan is confirmed, after detailed accounting, we will provide you with a satisfactory quotation!
4. To pay a deposit Arrange production
Reasonable production schedule, Consummate localization, Correction and the Welding technology, brings the best Barrier (Net) quality for you!
5. Product inspection
Casting with details outstanding, in addition to the internal product quality inspection and control standards, but also the European Union ENISO3834 aluminum alloy welding standards and hardware machine processing industry standards, to ensure high quality.
6. Global Trasportation
Professional logistics team, whether you choose logistics or need to deliver to our door, guarantee delivery on time!
![]() | 7. After Sales Services Provide detailed product installation instructions and video demonstrations, one-on-one professional customer service orders, ready to solve any problems for you, so that you can worry more, save time! |
Attribute | |
Country | China |
Brand | Shinestage |
Mod | F33P |
Custom Properties | |
Item | 290mm triangular truss |
Dimension | 290mm*290mm |
Maaterial | Aluminum 6082 T6 |
Main tube | 50*3mm |
Brace tube | 20*2mm |
Surface | Brace tube on 3 sides |
Weight | About 7.5kg/m |
Pin position | Diagonal |
Length | 0.5-4m |
Color | Silver, Powder coating Black, other color is available |
Package | Air bubble film |
Certificate | CE, TUV, SGS |
Application | Theatre, School, Hotel, Shop, Bar, Exhibition, Audio show, Fashion show, Trade show |
Attribute | |
Country | China |
Brand | Shinestage |
Mod | F33P |
Custom Properties | |
Item | 290mm triangular truss |
Dimension | 290mm*290mm |
Maaterial | Aluminum 6082 T6 |
Main tube | 50*3mm |
Brace tube | 20*2mm |
Surface | Brace tube on 3 sides |
Weight | About 7.5kg/m |
Pin position | Diagonal |
Length | 0.5-4m |
Color | Silver, Powder coating Black, other color is available |
Package | Air bubble film |
Certificate | CE, TUV, SGS |
Application | Theatre, School, Hotel, Shop, Bar, Exhibition, Audio show, Fashion show, Trade show |
