The F32 Ladder truss, a truss for vertical and horizontal rigs,This sy-stem is connected via a special conical connector system, which is joined together to a complete form fit by means of a copper hammer, creating optimal traction.Together with the Tolerance free conical connector system the straight elements lend themselves perfectly to use a a span exposed to bending stress.
Combined with F32 Truss they possess a broad range of applications.
| CODE | LENGTH |
F32-050 F32-100 F32-150 F32-200 F32-250 F32-300 F32-350 F32-400 | 290*50*500 290*50*100 290*50*150 290*50*2000 290*50*2500 290*50*3000 290*50*3500 290*50*4000 |
TüV approved
Also available in any non-standard length and shape
Tolerance free conical connector system
Compatible with F33
| Specifications F32 | ||
| Metric | Imperial | |
Height Width Main Tube Braces Weight Pin Position Material Connection | 290mm 50 mm 50 x 3 mm 20 x 2 mm ~4kg/m Diagonal EN AW-6082 T6 Cs5 | 11.42 in 1.97 in 1.97x 0.12 in 0.79 x 0.08 in ~8.8 lbs/m |
JUNCTIONS OR CONNECTION SYSTEM
- Service Process -
- Service Process -
Professional team and service to create a perfect stage for you
1. Learn Project Place Planning
professional team will have a comprehensive understanding based on the site size and project requirements you provide.
2. Design and determine Program
Professional design team, free design for you to meet your needs.
3. Quotation and contract signing
Once the plan is confirmed, after detailed accounting, we will provide you with a satisfactory quotation!
4. To pay a deposit Arrange production
Reasonable production schedule, Consummate localization, Correction and the Welding technology, brings the best Barrier (Net) quality for you!
5. Product inspection
Casting with details outstanding, in addition to the internal product quality inspection and control standards, but also the European Union ENISO3834 aluminum alloy welding standards and hardware machine processing industry standards, to ensure high quality.
6. Global Trasportation
Professional logistics team, whether you choose logistics or need to deliver to our door, guarantee delivery on time!
 | 7. After Sales Services Provide detailed product installation instructions and video demonstrations, one-on-one professional customer service orders, ready to solve any problems for you, so that you can worry more, save time! |
